Cal Test CP6770 High Voltage Differential Probe 70 MHz EU

Description

Measure floating high-voltage signals with the Cal Test CP6770-EU, a 70 MHz high voltage differential probe for EU power distribution, PV inverters, and high-voltage research labs. Its single differential channel, 100:1 and 1000:1 attenuation, low-noise active amplifier, and less than 5 ns rise time support differential measurements through a compatible oscilloscope.

The CP6770-EU uses analog signal transfer rather than internal sampling or waveform storage. Its waveform update rate is system dependent, while memory depth, vertical resolution, and hardware triggers are not provided in the probe specifications. A standard BNC connects to 1 MOhm oscilloscope inputs, and the stated frequency response includes optimized flatness with minimal phase-shift characteristics. The package uses an EU mains power adapter.

Key Features & Benefits of Cal Test CP6770-EU

• 70 MHz bandwidth with less than 5 ns rise time supports high-frequency differential measurements
• Single differential channel transfers floating voltage signals to compatible oscilloscope inputs
• 100:1 and 1000:1 attenuation settings adapt measurements to connected instruments
• Low-noise active differential amplifier supports the listed signal transfer configuration
• IEC 61010-031 CAT III 1000V specification defines the stated probe standard

Why Buy Cal Test CP6770-EU

Choose the Cal Test CP6770-EU when an oscilloscope requires differential measurement capability for EU-oriented power applications. Its 70 MHz bandwidth, less than 5 ns rise time, selectable 100:1 or 1000:1 attenuation, and low-noise active amplifier create a focused probe solution for floating measurements. The standard BNC interface works with listed 1 MOhm oscilloscope inputs, while the EU mains power adapter distinguishes this version from the North American model.

EU Power Testing And Warranty

The CP6770-EU is listed for safety-critical floating measurements in EU-standard power distribution, PV inverters, and high-voltage R&D labs. As an analog probe, it has no internal sample rate, memory depth, display, or hardware trigger specifications; waveform updating is system dependent. Its stated compliance is IEC 61010-031 CAT III 1000V Standard. The country of origin is USA/Taiwan. Warranty coverage is listed as 1 year, with verification specified at 12 months.
