Compliance West HT-10KVP AC/DC Hipot Tester

Description

Developed for combined dielectric evaluation, the Compliance West HT-10KVP-AC-DC 10kV AC/DC hipot tester applies controlled high-voltage testing from 0-10kVac and 0-14KVdc for transformers and electrical components. This benchtop insulation tester integrates digital voltage and current meters with adjustable trip settings for AC and DC withstand verification procedures.

The HT-10KVP-AC-DC combines AC and DC high-voltage generation circuits with manual sensitivity adjustment of 10mA AC and 5mA DC. Digital voltage and current meters provide measurement visibility during testing, while the industrial benchtop enclosure houses the internal control and protection circuitry. Operating from a 120V AC supply at 50/60 Hz, the unit maintains CAT II 1000V safety classification and functions within a 0°C to 40°C temperature range.

Key Features of Compliance West HT-10KVP-AC-DC

• 14KVdc output boundary: Performs DC testing to prevent insulation failures.
• 10kVac voltage capability: Applies AC stress to prevent dielectric defects.
• 10mA AC 5mA DC limits: Controls leakage current to prevent excessive exposure.
• Digital voltage current meters: Displays measurements to prevent reading errors.
• CAT II 1000V rating: Defines safety requirements to prevent improper operation.
• 50/60 Hz frequency range: Supports AC systems to prevent frequency mismatch.
• NIST traceable certification: Documents calibration to prevent audit gaps.

Test Configuration

The instrument connects high-voltage generation circuits, current monitoring electronics, adjustment controls, and digital display modules inside an industrial benchtop enclosure. The 120 VAC power configuration supplies the test platform while AC and DC output circuits manage controlled dielectric evaluation.

Industrial Applications

This hipot tester supports transformer inspection, electrical component qualification, and dielectric withstand testing where both AC and DC verification are required. Its dual voltage insulation verification capability allows technicians to evaluate component integrity across multiple test methods.

Warranty, CE Certificate and NIST Traceable Documentation

Manufactured in the USA, the HT-10KVP-AC-DC includes CE, UL, and NIST traceable documentation with a one-year manufacturer warranty. These records support electrical compliance audits, production validation procedures, and controlled test equipment management systems.
