Dranetz ES2201AE Electrical Standard Single Phase 20A
Dranetz ES2201AE Electrical Standard Single Phase 20A provides precise energy expense reporting for industrial facilities, utilizing a secondary standard PRT probe concept for monitoring thermal load impacts on single-phase electrical consumption metrics.
- Accuracy Rating: Industrial grade energy consumption precision.
- Measurement Range: 20A single-phase current monitoring.
- Media Compatibility: 85-253Vac/dc electrical power systems.
- Certification Standard: Harmonic analysis and IEEE standards.
- Build Material: Standard 144mm x 144mm enclosure.
In Stock
Description
Dranetz ES2201AE Electrical Standard Single-Phase 20A DataNode
The Dranetz ES2201AE is a high-precision electrical standard and energy monitoring instrument engineered to deliver elite operational performance for single-phase power analysis up to 20A. By addressing the requirement for detailed energy expense auditing, this DataNode allows users to compare energy use against complex rate structures, including peak/off-peak parameters and taxes. The metrological architecture of the ES2201AE ensures absolute traceability for harmonic analysis and energy demand, effectively minimizing measurement uncertainty in power quality assessments within commercial and industrial facilities.
Built for industrial longevity, the 144mm x 144mm instrument is designed to integrate seamlessly into InfoNode or Encore Series Software environments for comprehensive report generation. Its technical sophistication is centered on advanced algorithms that calculate aggregated energy expenses across multiple monitoring locations, providing detailed output in $/kWHr and $/kVARHr. As a high-trust solution for managing electrical stimulus, the Dranetz ES2201AE stands as a professional-grade metrology tool for optimizing energy efficiency, identifying cost-saving opportunities, and maintaining power system reliability.
Technical Specifications & Metrological Data
- Monitoring Spectrum: Single-phase electrical monitoring with a 20A current capacity.
- Voltage Range: Operates within 85-253Vac/dc for versatile industrial power compatibility.
- Economic Intelligence: Calculates energy usage, demand data, and costs based on complex rate structures.
- Diagnostic Suite: Advanced harmonic analysis and energy usage comparison algorithms.
- Report Generation: Aggregated expense reports including on-peak, partial-peak, and off-peak costs.
- System Integration: Compatible with Dranetz InfoNode or Encore Series Software for data management.
- Form Factor: Standard 144mm x 144mm panel-mount design for industrial control integration.
Dranetz ES2201AE Electrical Standard Metrology Specs
| Brand & Full Model SKU | Dranetz ES2201AE |
| Country of Origin | USA |
| Measurement Spectrum | Single Phase Voltage, Current, Power, and Energy |
| Current Capacity | Direct Input up to 20A AC/DC |
| Metrological Precision | ±0.02% of Reading (High-Precision Calibration Standard) |
| Voltage Range | Up to 600V RMS |
| Signal Architecture | Precision Analog-to-Digital conversion with thermal stability logic |
| Interface Intelligence | Local digital display and remote programmatic control |
| Standard Warranty | 1-Year Limited Warranty |
| Industrial Application | Metrology laboratory reference standard for verifying the accuracy of secondary watt-hour meters and electrical power analyzers. |
