HD Electric DVI-100T-K01 Digital Voltage Indicator 100kV Kit
HD Electric DVI-100T-K01 Digital Voltage Indicator 100kV Kit memitigasi risiko kecelakaan kerja pada sistem tegangan tinggi hingga 161kV dengan membedakan antara tegangan nominal dan induksi, menggunakan logika precision thermal calibration unit untuk memberikan pembacaan line-to-ground yang akurat pada aplikasi overhead maupun underground.
- Batas Tegangan: Hingga 161kV (99kV line-to-ground).
- Indikator Audio: Alarm deteksi tegangan aktif.
- Desain Fisik: Universal spline untuk attachment hotstick.
- Aplikasi: Mendukung pengujian titik uji elbow (underground).
- Fitur Display: LED auto-ranging visibilitas tinggi.
In Stock
Description
HD Electric DVI-100T-K01 Digital Voltage Indicator (100kV Kit)
The HD Electric DVI-100T-K01 is a professional-grade digital voltage indicator kit engineered to deliver elite operational performance for safety testing on system voltages up to 161kV. By addressing the requirement for clear diagnostic feedback, this instrument features a large auto-ranging LED display and audible alerts that effectively minimize measurement uncertainty during high-voltage audits. The metrological architecture of the DVI-100T allows users to distinguish between nominal and induced voltage levels, providing critical intelligence for line-to-ground measurements up to 99kV maximum.
Built for industrial longevity, the DVI-100T-K01 is housed in a rugged plastic case and includes both overhead hook and underground bushing probes for maximum versatility. Its technical sophistication is highlighted by a built-in universal spline for standard hotstick attachment and an auto shut-off feature to preserve its field-replaceable 9V battery. As a high-trust solution for managing electrical stimulus in utility environments, this kit stands as a critical safety tool for distinguishing energized lines from induced “ghost” voltages in both overhead and underground power distribution applications.
Technical Specifications & Metrological Data
- Voltage Capacity: Designed for system voltages up to 161kV (99kV line-to-ground max).
- Visual Intelligence: Large auto-ranging LED display for clear voltage level indication.
- Audible Alert: Integrated sounder provides immediate notification of detected voltage stimulus.
- Metrological Differentiation: Capability to distinguish between nominal and induced voltage levels.
- Interface Logic: Built-in universal spline for seamless standard hotstick integration.
- Kit Versatility: Includes overhead hook probe and 15, 25, and 35kV class underground bushing probes.
- Power Management: Powered by a 9V alkaline battery with an integrated auto shut-off function.
HD Electric DVI-100T-K01 Digital Voltage Indicator Specs
| Brand | HD Electric Company |
| Model | DVI-100T-K01 |
| Voltage Capacity | System voltages up to 161kV (Reads 0.1kV to 99kV Line-to-Ground) |
| Metrological Feature | Distinguishes between Nominal and Induced (Ghost) voltages |
| Visual Intelligence | Large 3-digit auto-ranging LED display; Audible alert |
| Mechanical Interface | Built-in universal spline for standard hotstick attachment |
| Kit Versatility | Includes overhead hook and 15/25/35kV underground bushing probes |
| Country of Origin | USA |
| Warranty | 1 Year |
