Imada ZTA-LM-1100 Load Monitoring Force Gauge 1100 LBF – ZTA-LM-1100

Imada ZTA-LM-1100 Load Monitoring Force Gauge (1100 lbf)

The Imada ZTA-LM-1100 is a flagship Load Monitoring Force Gauge engineered to deliver elite operational performance for characterizing complex high-capacity stimulus in industrial tension and compression audits. By addressing the requirement for surgical accuracy in dark or low-visibility environments, this instrument utilizes a high-visibility electro-luminescent (EL) display and a high-speed processor capable of transmitting 2,000 data points per second. The metrological architecture of the ZTA-LM-1100 ensures absolute traceability, providing high-fidelity oversight with a 1,000-point internal memory and a remote sensor with a 6-foot cable for exhaustive validation of heavy-duty force applications up to 1100 lbf.

Built for industrial longevity and professional-grade safety validation, the ZTA-LM-1100 is a high-trust solution for managing stimulus in manufacturing and quality control audits. Its technical sophistication is centered on its color-coded LED indicators for Go/No Go testing and versatile output logic (USB, RS-232C, Digimatic, and Analog), establishing it as a professional-grade metrology asset for certifying force margins. Providing the repeatable results and rigorous verification required for identifies hardware anomalies, this gauge features an ergonomic metal construction and 200% over-capacity protection, serving as the definitive tool for engineers requiring real-time force and displacement data integration.

Technical Specifications & Metrological Data

• Force Fidelity: High-capacity characterization up to 1100 lbf (4,400 lbs compression only).
• Sampling Performance: High-speed processing and transmission of 2,000 data points per second.
• Visual Infrastructure: Electro-luminescent (EL) display and color-coded Go/No Go LED indicators.
• Memory Logic: Internal storage for 1,000 data points with USB flash drive export capability.
• Interface Logic: Comprehensive connectivity via USB (virtual COM), RS-232C, and Digimatic.
• Safety Metrics: 200% Full Scale overload capacity with integrated overload alarm and signal.
• Kit Contents: Includes remote sensor, ZT Logger software, attachments, and NIST-traceable certificate.
