Keysight DSOX2014A Digital Oscilloscope, 4 Channel, 100MHz
Keysight DSOX2014A Combine 100 MHz bandwidth with 4 analog channels at 2 GSa/s and 8 optional digital channels for embedded design, education, and manufacturing test on a benchtop platform.
- 100MHz fits general debugging.
- 4 analog channels compare signals.
- 8 optional digital channels extend logic.
- 50,000 wfms/s exposes fast glitches.
- 1 Mpts keeps trace history.
In Stock
Description
Measure four analog signals with the Keysight DSOX2014A, a 100 MHz InfiniiVision digital oscilloscope for embedded design, education, and manufacturing testing. Its 2 GSa/s sampling, 1 Mpts record length, 50,000 wfms/s capture rate, and 8.5-inch WVGA LCD support multi-channel waveform review. The listed package includes four N2862B 150 MHz passive probes.
The DSOX2014A provides four analog channels, 1 mV/div to 5 V/div sensitivity, and a 5 ns/div to 50 s/div timebase with ±25 ppm accuracy. Edge, pulse-width, pattern, and video triggers help isolate signal events, while 33 automatic measurements support routine checks. I2C, SPI, and UART/RS-232 analysis is optional, as are eight digital channels, the 20 MHz function generator, LAN, and GPIB. USB Host/Device provides the listed standard interface.
Key Features & Benefits of Keysight DSOX2014A
- 100 MHz bandwidth across four analog channels supports general-purpose embedded testing
- 2 GSa/s sampling captures related waveforms during manufacturing verification
- 1 Mpts record length stores waveform data for laboratory review
- 50,000 wfms/s capture rate supports rapid waveform activity inspection
- Four included N2862B 150 MHz probes support the four-channel setup
Why Buy Keysight DSOX2014A
Select the Keysight DSOX2014A when four analog channels are needed for embedded design, education, or manufacturing test. Its 1 Mpts record length, 50,000 wfms/s capture rate, 33 automatic measurements, and included four-probe package support routine bench work. Optional eight digital channels can expand the instrument toward mixed-signal testing, while optional serial analysis, function generation, LAN, and GPIB add configuration-specific capabilities. The listed 100 MHz bandwidth matches the included N2862B probe specification.
Embedded Testing And Warranty
The DSOX2014A is specified for general-purpose embedded design, education, and manufacturing test. Safety information includes UL 61010-1 and IEC 61010-1, with a maximum input voltage of 300 Vrms, CAT I. Optional functions include eight digital channels, I2C/SPI/UART-RS232 analysis, a 20 MHz function generator, LAN, and GPIB. The warranty is listed as 3 years, while no recalibration interval is provided. Country of origin is Malaysia.
Keysight DSOX2014A Specs
| Brand | Keysight Technologies |
| Full Model Number | DSOX2014A |
| Country of Origin | Malaysia |
| Series Family | InfiniiVision 2000 X-Series |
| Form Factor | Benchtop |
| Bandwidth | 100 MHz |
| Number of Analog Channels | 4 |
| Number of Digital Channels | 8 (Optional Upgrade) |
| Max Real-time Sample Rate | 2 GSa/s |
| Max Record Length | 1 Mpts |
| Waveform Capture Rate | 50,000 wfms/s |
| Vertical Resolution | 8-bit |
| Vertical Sensitivity | 1 mV/div to 5 V/div |
| DC Gain Accuracy | ±3% full scale |
| Time Base Range | 5 ns/div to 50 s/div |
| Time Base Accuracy | ±25 ppm |
| Input Impedance | 1 MΩ ± 2% // 16 pF |
| Input Coupling | AC, DC |
| Maximum Input Voltage | 300 Vrms, CAT I |
| Standard Trigger Types | Edge, Pulse Width, Pattern, Video |
| Serial Bus Analysis | I2C, SPI, UART/RS-232 (Optional) |
| Automatic Measurements | 33 built-in |
| Built-in Function Generator | Yes (Optional 20 MHz) |
| Display Specifications | 8.5-inch WVGA LCD |
| I/O Interfaces | USB Host/Device, LAN (Opt), GPIB (Opt) |
| Standard Probes Included | 4 x N2862B (150 MHz) |
| Safety Ratings | UL 61010-1, IEC 61010-1 |
| Application | General-purpose embedded design, education, and manufacturing test. |
