Keysight MSOS104A Infiniium S-Series MSO 4 Ch 1 GHz
Keysight MSOS104A Infiniium S-Series MSO 4 Ch 1 GHz streamlines the debug of 1 GHz embedded designs by utilizing a secondary standard PRT probe monitoring framework to synchronize analog and digital data with industry-best signal integrity.
- Analog Bandwidth: 1 GHz bandwidth on 4 channels.
- Digital Interface: 16 integrated high-speed digital channels.
- Calibration Fixture: Ships with dedicated logic probe calibration tools.
- System Speed: Fast data offload for high-throughput testing.
- Input Range: Supports a wide range of over 100 specialized probes.
In Stock
Description
Keysight MSOS104A Infiniium S-Series MSO (1 GHz, 4+16 Ch)
The Keysight MSOS104A is a flagship 1 GHz mixed-signal oscilloscope engineered to deliver elite operational performance for characterizing high-speed stimulus with industry-leading signal integrity. By addressing the requirement for surgical accuracy in complex embedded system audits, this instrument utilizes up to 16 bits of vertical resolution and a low-noise front end to effectively minimize measurement uncertainty. The metrological architecture of the MSOS104A ensures absolute traceability across 4 analog and 16 digital channels, providing high-fidelity oversight through hardware-accelerated processing and an expansive 800 Mpts deep memory for capturing critical timing relationships.
Built for industrial longevity and high-stakes laboratory research, the MSOS104A is a high-trust solution for managing stimulus in advanced telecommunications and digital verification. Its technical sophistication is centered on a powerful motherboard and a 240 GB removable SSD for secure data management, establishing it as a professional-grade metrology asset. Providing the repeatable results and rigorous verification necessary for certifying multi-lane architectures, this MSO features 50 automated measurements and a 16-channel flying lead logic probe, serving as the definitive tool for engineers requiring high-resolution mixed-signal analysis.
Technical Specifications & Metrological Data
- Mixed-Signal Characterization: 1 GHz analog bandwidth (4 Ch) and 16 integrated digital channels.
- Vertical Fidelity: Up to 16 bits of vertical resolution for surgical signal reproduction.
- Memory Depth: Massive 800 Mpts record length for high-resolution capture across all channels.
- System Integrity: Low-noise front end with a superior time base and hardware signal processing.
- Computing Platform: 240 GB removable SSD, capacitive touch screen, and fast data offload.
- Logic Analytics: Includes 16-channel flying lead logic probe and calibration fixture.
- Standard Package: Ships with N2873A passive probes and 8 GHz BNC calibration cable.
Keysight MSOS104A Metrology Specs
| Brand & Full Model SKU | Keysight MSOS104A (Mixed Signal) |
|---|---|
| Country of Origin | USA |
| Bandwidth & Rise Time | 1 GHz | Tr < 400 ps |
| Analog & Digital Channels | 4 Analog + 16 Integrated Digital Channels |
| Max Real-Time Sample Rate | 20 GSa/s (2 Ch) / 10 GSa/s (4 Ch) |
| Waveform Update Rate | Hardware-accelerated Signal Processing |
| Max Memory Depth | 100 Mpts (Std) / 800 Mpts [Opt] |
| Vertical Resolution & High-Res Mode | 10-bit ADC Native Performance |
| Input Sensitivity & Noise Floor | Low-noise path for high-speed logic thresholds |
| Timebase Range & Jitter | < 100 fs rms Intrinsic Jitter |
| Hardware-Based Triggers | Full Suite + Logic Pattern Search & Mark |
| Protocol Analysis & Decoding | USB 2.0, DDR2/3, PCIe Gen 1 |
| Spectral Analysis | Gated FFT for RF-Logic Timing Correlation |
| Display & UI Architecture | 15-inch Touch Display (Windows 10 IoT) |
| Connectivity & Interface | Standard USB/LAN/Video Output |
| Multi-Instrument Integration | 6-in-1: Scope, Logic Analyzer, Protocol, DVM, Counter, FFT |
| Standard Warranty & Service Interval | 3 Years Standard Warranty | 12 Months Recalibration |
| Metrological Compliance | NIST Traceable Factory Calibration |
| Industrial Application | Digital bus troubleshooting, automotive electronic audits, and FPGA-based system validation. |
