Miller Multimatic 255 Pulsed Multi-Process Welder 208-575V (907728)
Miller Multimatic 255 Pulsed Multi-Process Welder 208-575V (907728) simplifies complex tig welders diagnostics through its rugged engineering and high-fidelity sensor memory for professional-tier results.
- Duty Cycle: 60% @ 230A / 100%
- Amperage Range: 20-350A
- Welding Process: MIG, Pulsed MIG, Flux-Cored, Stick,
- Full Model Number: Multimatic 255 Pulsed Multi-Process
- Power Source Type: Inverter
In Stock
Description
Miller Multimatic 255 Pulsed Multiprocess Welder 208-575V 907728 Specs
The Miller Multimatic 255 Pulsed is the highly adaptable, top-tier solution for professional shops requiring industrial-level versatility. This machine excels in MIG, Pulsed MIG (for superior aluminum/stainless results), Stick, and DC TIG. The 208-575V Auto-Line technology allows seamless connection to virtually any power input, making the Miller Multimatic 255 ideal for large facilities or field work with varied power sources. Featuring a large color display and Auto-Set Elite, the Miller Multimatic 255 Pulsed Multi-Process Welder simplifies complex pulsed welding, delivering premium results across all metals and processes.
- Brand: Miller
- Model: Multimatic 255
- MPN/SKU: 907728
- Processes: MIG (GMAW), Pulsed MIG, Flux-Cored (FCAW), Stick (SMAW), DC TIG (GTAW)
- Input Voltage: 208–575V, 1/3-Phase
- Output Range: 20–350 Amps
- Duty Cycle: 230A @ 60% (MIG), 275A @ 60% (Stick)
- Wire Feed Speed: 50–850 IPM
- Pulse MIG: Yes, included
- Display: 4.3″ Color LCD Interface
- Technology: Auto-Set Elite, Fan-On-Demand, True Multi-Voltage Plug (MVP)
- Weight: 84 lbs (38.1 kg)
- Dimensions: 21.5 in H × 12.5 in W × 23 in D
- Material Compatibility: Mild Steel, Aluminum, Stainless Steel
- Applications: General Fabrication, Light Industrial, Repair & Maintenance
- Included Accessories: MIG gun, power cord, clamp, flow regulator (depends on bundle)
- Warranty: 3-Year Miller True Blue Warranty
Miller Multimatic 255 Specs
| Brand | Miller Electric |
| Full Model Number | Multimatic 255 Pulsed Multi-Process (907728) |
| Country of Origin | USA |
| Welding Process | MIG, Pulsed MIG, Flux-Cored, Stick, DC Lift-Arc TIG |
| Power Source Type | Inverter |
| Input Voltage | 208-575V (Auto-Line Technology) |
| Input Phase | Single and Three Phase |
| Rated Output Amperage | 230A @ 25.5V (Single Phase 240V) |
| Duty Cycle | 60% @ 230A / 100% @ 170A |
| Amperage Range | 20-350A |
| Open Circuit Voltage (OCV) | 87VDC |
| Wire Feed Speed Range | 50-800 ipm |
| Electrode/Wire Diameter Range | 0.023" - 0.045" Solid Steel / 0.035" - 0.045" Aluminum |
| Maximum Material Thickness | 1/2" (12.7 mm) Steel |
| Protection Class | IP21 |
| Insulation Class | Class H |
| Cooling Method | Fan-On-Demand |
| Net Weight | 84 lbs (38 kg) |
| Dimensions | 19.24" x 13.75" x 26.25" |
| Special Features | Auto-Set Elite, 7-inch Color LCD, Auto-Line Power, Pulsed MIG for thin aluminum |
| Gas Requirement | Ar, Ar/CO2, CO2 |
| Arc Ignition Type | Direct Contact MIG / Lift-Arc TIG |
| Standard Accessories Included | 15ft Bernard BTB 250A Gun, Flow Gauge Regulator, Drive Rolls |
| Compliance/Certification | ANSI, CSA |
| Standard Warranty | 3-Year True Blue Warranty |
| Application | Manufacturing, fabrication, mechanical contractors, and fleet maintenance. |
