Dranetz HDPQ SPGA550 PQ Analyzer (100A Clamp Kit)

Product Highlights

The Dranetz HDPQ Guide goes well beyond the requirements of the PQ standards by including transient capture capabilities for voltage and current, such as: transients to 32 microseconds, peak sample transients, and advanced waveshape change transients that can identify changes from cycle to cycle.

• Safe & Rugged
• IP65 Enclosure
• Arc Flash Safety
• UL/cUL listed and CE approved
• Power supply cable retainer
• Wire management in easel and hook
• Automatic circuit detection and feedback on proper connection of the instrument
• Precision – 16-25Hz, 42.5-69Hz Capabilities
• High Definition PQ & Energy Monitoring – 1000Vrms, AC/DC, 512 samples/cycle
• High Speed Digitized Transients to 1us – to 2000Vpk
• Eight channels, 4 voltage & 4 current
• AnswerModules – Sag directivity, PF capacitor identification, motor – automatic event categorization
• Advanced PQ – IEC 61000-4-30 Class A & IEEE 1159 compliant
• Harmonics – IEC 61000-4-7, IEEE 519
• Transient capabilities – V & I – waveshape triggers. Beyond standards
• IEE 1459 Advanced Power Measurements
• 10,000 cycle pre/post trigger buffer EN 50160 Ed 3

Communications:

• Ethernet, Wi-Fi, USB, Bluetooth
• VNC for full remote control
• Apple & Android apps with real time metering and alarm Dashboard
• Enhanced Dranetz tech support

User Interface

• Automatic setups – PQ, D&E
• Tablet-like GUI, Icon driven, taskbar shortcuts, Dashboard

Productivity

• Mini-report – XML file. Easily uploaded and emailed
• Power quality & energy Dashboard’s for real time alarming
• AnswerModules – automatic event categorization
• Dran-View 7
• Data analysis and reporting
• Rescue kit
• Post processing
