Keysight DSOX2012A InfiniiVision Oscilloscope (2 Ch)
Keysight DSOX2012A InfiniiVision Oscilloscope (2 Ch) streamlines educational lab experiments by integrating a precision thermal calibration unit with a 50,000 wfm/s update rate and upgradable instrument modules.
- Fast Updates: MegaZoom IV ASIC technology for signals.
- Memory Tools: Includes standard segmented memory and 100kpts.
- Large Display: High-resolution 8.5-inch WVGA color screen display.
- Mixed Signal: Upgradable 8-channel integrated logic analyzer option.
- Built-in Help: Multi-language interface with embedded guidance system.
In Stock
Description
Keysight DSOX2012A InfiniiVision Digital Oscilloscope (100 MHz, 2 Ch)
The Keysight DSOX2012A is a premier 100 MHz InfiniiVision oscilloscope engineered to deliver elite operational performance for characterizing electrical stimulus through the sophisticated MegaZoom IV custom ASIC architecture. By addressing the requirement for professional-grade diagnostics in education and R&D labs, this instrument utilizes a 2 GSa/s sample rate and a fast 50,000 wfm/s update rate to effectively reveal elusive signal glitches and timing errors. The metrological architecture of the DSOX2012A ensures absolute traceability, providing high-fidelity oversight with standard segmented memory and advanced hardware triggers for exhaustive hardware audits.
Built for industrial longevity and professional-grade electronic validation, the DSOX2012A is a high-trust solution for managing stimulus in complex analog and mixed-signal designs. Its technical sophistication is centered on its fully upgradable platform, including options for an 8-channel logic analyzer and WaveGen function generator, establishing it as a professional-grade metrology asset for certifying system-level performance. Providing the repeatable results and rigorous verification necessary for professional-grade diagnostics, this 100 MHz workstation features a high-resolution 8.5-inch display and advanced math functions, serving as the definitive tool for engineers requiring industry-proven technology in an entry-level package.
Technical Specifications & Metrological Data
- Bandwidth Fidelity: 100 MHz analog characterization across 2 analog channels (upgradable).
- Sampling Performance: High-speed 2 GSa/s real-time sample rate.
- Capture Speed: 50,000 waveforms per second via MegaZoom IV deep memory technology.
- Visual Infrastructure: High-resolution 8.5-inch WVGA color display.
- Mixed Signal Suit: Integrated 8-channel MSO logic analyzer capability (optional/upgradable).
- Analytical Logic: Advanced math functions and hardware triggers (Edge then Edge, Runt, Setup/Hold).
- Reliability Metrics: 3-year standard warranty and a 2-year calibration cycle for documented accuracy.
Keysight InfiniiVision DSOX2012A Metrology Specs
| Brand & Full Model SKU | Keysight Technologies DSOX2012A |
| Country of Origin | Malaysia |
| Bandwidth & Rise Time | 100 MHz | ≤ 3.5 ns |
| Analog & Digital Channels | 2 Analog Channels |
| Max Real-Time Sample Rate | 2 GSa/s (Interleaved), 1 GSa/s (Per Channel) |
| Waveform Update Rate | 50,000 wfm/s (MegaZoom IV) |
| Max Memory Depth | 1 Mpts (Standard) | 100 kpts (Segmented Memory) |
| Vertical Resolution & High-Res Mode | 8-Bit | 12-Bit High-Res |
| Input Sensitivity & Noise Floor | 1 mV/div to 5 V/div | ~250 µVrms |
| Timebase Range & Jitter | 5 ns/div to 50 s/div | < 100 ps rms |
| Hardware-Based Triggers | Edge, Pulse Width, Pattern, Video |
| Protocol Analysis & Decoding | I2C, SPI, UART/RS232, CAN, LIN [Optional Upgrade] |
| Spectral Analysis | Standard FFT (64k pts) |
| Display & UI Architecture | 8.5-inch WVGA LCD |
| Connectivity & Interface | USB Host/Device, LAN/VGA [Optional Upgrade] |
| Multi-Instrument Integration | Integrated 3-digit DVM and 20 MHz WaveGen [Optional Upgrade] |
| Standard Warranty & Service Interval | 3 Years | 24-Month Calibration |
| Metrological Compliance | ISO/IEC 17025, NIST Traceable |
| Industrial Application | Standard laboratory and manufacturing diagnostics requiring high waveform update rates to capture signal integrity glitches in embedded designs. |
