Tektronix MDO3104 Mixed Domain Oscilloscopes (1 GHz, 4 Ch)
Tektronix MDO3104 Mixed Domain Oscilloscope (1 GHz, 4 Ch) provides ultimate visibility for high-speed embedded systems by pairing 1 GHz bandwidth with a secondary standard PRT probe interface for precise, drift-free mixed-signal synchronization.
- Analog Performance: 1 GHz bandwidth 4 channels.
- RF Capability: 3 GHz optional spectrum analyzer.
- DVM Feature: 4-digit AC/DC RMS voltmeter.
- Sample Performance: 5 GS/s high-speed sampling.
- Display Specs: 9-inch WVGA color display.
In Stock
Description
Tektronix MDO3104 — Mixed Domain 6-in-1 Oscilloscope (1 GHz / 4-Ch)
The Tektronix MDO3104 is a flagship 1 GHz mixed-domain oscilloscope engineered to deliver elite operational performance for high-speed embedded design and RF characterization. By addressing the requirement for synchronized multi-domain analysis, this 6-in-1 integrated instrument combines a high-bandwidth oscilloscope with a hardware-integrated spectrum analyzer (9 kHz to 3 GHz). The metrological architecture of the MDO3104 ensures absolute traceability, utilizing a 5 GS/s sample rate and a 10 Mpts record length to effectively minimize measurement uncertainty when debugging complex wireless communications and EMI interference. Built for industrial longevity, the MDO3104 features a >280,000 wfm/s capture rate and standard passive probes with an industry-leading 3.9 pF capacitive loading. Its technical sophistication is enhanced by optional 50 MHz arbitrary function generation, 16-channel logic analysis, and a comprehensive serial protocol suite. With its compact 5.8-inch deep footprint and fully upgradable performance path, the Tektronix MDO3104 stands as a high-trust solution for managing massive electrical stimulus with the professional-grade accuracy and reliability required for advanced industrial metrology.
Technical Specifications & Metrological Data
- Performance Ceiling: 1 GHz bandwidth with 4 analog channels and 5 GS/s sampling.
- Mixed Domain Power: Integrated hardware spectrum analyzer (9 kHz standard, upgradable to 3 GHz).
- Waveform Fidelity: >280,000 wfm/s update rate for capturing sub-nanosecond anomalies.
- Metrological Precision: 10 M record length on all channels with integrated 4-digit DVM and 5-digit counter.
- Stimulus & Logic: Optional 50 MHz AFG and 16-channel logic analyzer (121.2 ps resolution).
- Probing Excellence: Includes 1 GHz passive probes with ultra-low 3.9 pF capacitive loading.
- Strategic Scalability: Fully upgradable bandwidth, spectrum analyzer range, and analysis modules.
Tektronix MDO3104 Metrology Specs
| Brand & Full Model SKU | Tektronix MDO3104 (Mixed Domain Oscilloscope) |
|---|---|
| Country of Origin | USA / China |
| Bandwidth & Rise Time | 1 GHz | Tr < 350 ps |
| Analog & Digital Channels | 4 Analog + 16 Digital [Optional] + 1 Spectrum Analyzer (9 kHz - 1 GHz) |
| Max Real-Time Sample Rate | 5 GSa/s (Half) / 2.5 GSa/s (All Channels) |
| Waveform Update Rate | > 280,000 wfm/s (FastAcq Technology) |
| Max Memory Depth | 10 Mpts (Standard) |
| Vertical Resolution & High-Res Mode | 8-bit (Up to 11-bit with Hi-Res) |
| Input Sensitivity & Noise Floor | 1 mV/div to 1 V/div (50 Ohm) | 1 mV/div to 10 V/div (1 MOhm) |
| Timebase Range & Jitter | 400 ps/div to 1000 s/div | < 4 ps rms |
| Hardware-Based Triggers | Full Advanced Trigger Suite + Wave Inspector Control |
| Protocol Analysis & Decoding | High-Speed Serial Analysis (USB 2.0, HSIC) [Optional] |
| Spectral Analysis | True Hardware SA (Standard 1 GHz / Opt. 3 GHz) |
| Display & UI Architecture | 9-inch WVGA High-Definition Interface |
| Connectivity & Interface | USB, LAN (LXI Class C), HDMI Out |
| Multi-Instrument Integration | Complete 6-in-1 Bench Solution (Integrated AFG/DVM) |
| Standard Warranty & Service Interval | 3 Years | 12 Months Recalibration |
| Metrological Compliance | ISO/IEC 17025 / NIST Traceability |
| Industrial Application | High-speed digital system validation, RF signal integrity, and comprehensive multi-domain bench audits. |
